Liquid Cleaner
Liquid Cleaner & Suction Device ?
By using compressed air as the power source, Liquid Cleaner & Suction Device is a powerful and innovative product that is available to transfer, collect, suck, and discharge materials, especially for liquid(cutting oil, oil, chip mixture, and sludge mixture).
Features
- It is easy to use and there is no trouble.
- As there is no rotating channel and it doesn’t need electricity, there is no risk of explosion.
- When it sucks certain amounts, the suction automatically is turned off by the Shut-off Valve.
- Alternative containers may be used (200 Liter Drum).
- Compressed air is used as a power source.
- It is possible to suck and discharge. (TC50 / TC100)
Purpose to Use
- Suction and injection of liquid, chip, and sludge mixture.
- Cleaning water, cutting oil, and oil tank.
- It is easy to remove precipitation, drossing, and remaining water.
- Discharging liquid in the drum and tank.(TC50 / TC100)
SD400D Series Specification
Weight : 20kg / Lift : 3M / Horizontal Transfer : 15M
| Category | Degree of vacuum | Air consumption | Liquid suctionrate | ||||
|---|---|---|---|---|---|---|---|
| ㎏/㎠ | PSI | ㎜Hg | ㎜Aq | IchAq | ℓ/min | SCFM | ℓ/min |
| 4 | 57 | 253 | 3,439 | 135.4 | 756 | 26.5 | 80 |
| 5 | 71 | 315 | 4,284 | 168.7 | 877 | 30.9 | 90 |
| Size | TC50 : 790 L × 460 W × 890 H 20㎏ | TC100 : 736 L × 560 W × 890 H 33㎏ | |||||
